Item

Specification

Optional

Reed Space

Nominal reed width

190.210.230.250.280.340.360cm

Useful Reading width

Same as nominal width maximum reduction 60cm(190-250cm)
Same as nominal width maximum reduction 80cm(>280cm)

Streth nozzle

Working range

Short yarn:100s-5s Long yarn:50D-900D

Welfsection

2-color mixing,2-color at-will,4colors.

Drive

Hypert start motor

For top、and locate electromagenetic brake

Use button for start.stop,forward and reverse

Welf insertion

Main and sub-nozzles combined system

Profile reed

Auxiliary main nozzle

Shedding

Adive shedding cam;the most heald frame to 8

Dobby shedding cam;the most heald Frame to 16

Electronnic big jacquard weave aperture,grain needle 1536 2688 5120 6144

Let-off

Flange Dia

Electronic let-off(EL-O)with automatic reversing device

Onilateral positive let-off

Bilateral double warp beam let-off

800mm 914mmMTU

Take-up

MTU mechanical take-up

ETU:electronic take-up

Max.take-up Dia

600mm

Welf density range

MTU:6.6-80.5picks/cm ETU:9.8-118picks/cm

15-204picks.inch 25-300picks.inch

Weaving length count

Board display,take the function of fixed measure stop

Weft Yarn fault

Floor-mounted

Beating

Crank type beating,muitiple sley sword beating
4links(reed space up to 280cm)
6links(reed space 280cm)
Intermediate rocking supporter

Measuring/storing

Feeding device free drum pooling

Weft yarn stand

Console-model double tube gauzo

Yain and treatment

Planetary gear motion

selvedge

Catch cord type

cutter

Mechanical cutter

lubrication

The main transmission part for the oil bath way,the centralism refueis

Auto-stop motion

Edge supporting

Reflective weft feeler,including weft arrival angle indication

Warp yain fault

Elctric feeling system,6rows of dropper

others

Stop motion for selvage and catch cord yain

Stop cause indication

Message on board,4-color lamp for indicating cause
